Trulux Standard Grade COB Pro Kit - IP54

SERIES

C-AML-STL-COB-PROKIT

Designed for lighting professionals, COB Series Pro Kits contain all of the essential installation components needed for basic single color linear lighting systems - just add a controller or dimmer and you’re all set. Speed installations by taking out the guess work and questioning compatibility.

Ready to install 24V DC tape light pro kit
Includes 96W hardwire power supply and install accessories
Seamless COB tape light in High Output grade
Available in 2700K, 3000K, or 4000K with 90+ CRI
Up to 413Lm per foot performance
Cuttable every 1.97” with 16.4ft max run
Create custom length power feeds and jumper wires
IP54 rating, protective nano-coating
Dimmable (5-100%) with most ELV, TRIAC dimmers
cULus Listed tape light for indoor dry locations
50,000 hours rated life / 5-year limited warranty

Trulux Standard Grade COB Pro Kit - IP54

Specifications

Performance

Input Voltage

24V DC

CCT

2700K / 3000K / 4000K

Wattage

2.19W/ft

Optics (Degree)

120 degrees

CRI

90+

Cut Increment

1.97 Inch

Max Run

16.4ft

Rated Life (Hr)

50,000 Hours

Temperature Range

5°C (41°F) to 70°C (158°F)

Dimming

Dimmable (5-100%) with most ELV, TRIAC dimmers

Lumens

220Lm/ft

Certification

Safety Rating

cULus Listed

Ordering Information

Item Number	Length	Input Voltage	CCT	CRI	Wattage	Lumens	Max Run	IP Rating	UOM
STL-COB-UWW-PROKIT-16	16.4 Foot	24V DC	2700K	90	2.19 W/ft	180	23 ft	IP54	Each
STL-COB-WW-PROKIT-16	16.4 Foot	24V DC	3000K	90	2.19 W/ft	200	23 ft	IP54	Each
STL-COB-WH-PROKIT-16	16.4 Foot	24V DC	4000K	90	2.19 W/ft	220	23 ft	IP54	Each
