Trulux Spec Grade Tape Light RGBW

SERIES
C-AML-SPTL-RGBW

RGB + Tunable CCT tape light is the ultimate solution in color changing RGB linear lighting technology. With RGB+TW, not only do you have a virtually unlimited RGB palette of color combinations, you also have the ability to adjust true white light ranging from 2700K up to 6000K. Providing intense color saturation, transition effects, and fade to white lighting effects.

  • Dynamic RGB+Tunable CCT color mixing capabilities
  • Create millions of color combinations perfect for impactful installations
  • Features 3-in-1 RGB LEDs with alternating 2700K & 6000K LEDs
  • Consumes up to 7 watts per foot
  • Control via DMX for color change and dimming (requires DMX receiver)
  • Run lengths up to 13.1 feet and cuttable every 3.94"
Trulux Spec Grade Tape Light RGBW
Trulux Spec Grade Tape Light RGBW

Performance

Input Voltage
24V DC
CCT
2700K-6000K
Wattage
7W/ft
Optics (Degree)
120 degrees
Cut Increment
2.46 Inch
Max Run
16.4ft
Rated Life (Hr)
50,000 Hours
Temperature Range
5°C (41°F) to 70°C (158°F)
Lumens
350Lm/ft

Certification

Safety Rating
cULus Listed
Item Number Length Input Voltage CCT CRI Wattage Lumens Max Run IP Rating UOM
SPTL-RGBW 16.4 Foot 24V DC RGBW 90+ 7 W/ft 350 16.4 ft IP54 Each
SPTL-RGBW-CC Custom Cut 24V DC RGBW 90+ 7 W/ft 350 16.4 ft IP54 Foot
