Trulux 4MM COB Tape Light Static White
SERIES
C-AML-TL4MM
COB Tape Light features uniform illumination without the need for additional diffused covers or accessories. Featuring a premium seamless line of light making it an ideal solution for areas with low clearance or reflective surfaces to eliminate virtually all dotting or spot-glare effects.
- Seamless COB design in ultra small 4mm profile that eliminates virtually all LED dotting
- Available in 2700K, 3000K, and 4000K
- 90+ color rendering index
- Lumen output ranging from 210Lm to 240Lm per foot
- Cuttable every 1.97” with 16.4ft max run
- Easy installation featuring 3M VHB adhesive backing
- Available in IP54 coated
- Dimmable (5-100%) with most ELV, TRIAC dimmers
- cULus Listed for indoor dry/damp locations
- 50,000 hours rated life
- Suitable for use in closets when used in an enclosed extrusion based on NFPA 70, NEC section 410.16 (A)(3) and 410.16 (C)(5)
Performance
Input Voltage
24V DC
CCT
2700K / 3000K / 4000K
Wattage
2.43W/ft
Optics (Degree)
120 degrees
CRI
90+
Cut Increment
1.97 Inch
Max Run
16.4ft
Rated Life (Hr)
50,000 Hours
Temperature Range
5°C (41°F) to 70°C (158°F)
Dimming
Dimmable (5-100%) with most ELV, TRIAC dimmers
Lumens
240Lm/ft
Certification
Safety Rating
cULus Listed
Indoor
Y
| Item Number | Length | Input Voltage | CCT | Wattage | Lumens | Max Run | IP Rating | UOM |
|---|---|---|---|---|---|---|---|---|
| TL4MM-COB-27K-16 | 16.4 Foot | 24V DC | 2700K | 2.43 W/ft | 210 | 16.4 ft | IP54 | Each |
| TL4MM-COB-30K-16 | 16.4 Foot | 24V DC | 3000K | 2.43 W/ft | 230 | 16.4 ft | IP54 | Each |
| TL4MM-COB-40K-16 | 16.4 Foot | 24V DC | 4000K | 2.43 W/ft | 240 | 16.4 ft | IP54 | Each |
