CCV Driver 100 Watts 24V DC

SERIES
CCV-DR100-24
CC & 24VDC DRIVER, 100W, 90-305V INP, cURus, CLASS 2, IP65,1-10VDC,PWM OR RESIST. DIMMING
CCV Driver 100 Watts 24V DC
CCV Driver 100 Watts 24V DC

Performance

Input Voltage
90-305V AC
Output Voltage
24V DC
Input Frequency
47-63 Hz
Output Frequency
4A
Wattage
100 W
Power Factor
≥0.98/115V AC ≥0.95/230V AC ≥0.92/277V AC
Minimum Load
40 W
Temperature Range
-40C (-40F) to 90C (194F) degrees
Dimming
PMV 0-10V

Physical

Weight
2.3648 lbs
Width
2.67 Inch
Length
8.97 Inch
Height
1.52 Inch

Certification

Safety Rating
cURus Recognized
Airtight
Y
IP Rating
IP65
Location Rating
Wet
Indoor
Y
Outdoor
Y
Class 2
Y
Item Number Length Input Voltage Wattage IP Rating UOM
CCV-DR100-24 8.97 Inch 90-305V AC 100 W IP65 Each
