DMX RGBW Wall Control

SERIES
CTRLW-DMXB-RGBW-4Z

Mastermind a dynamic lighting scheme with the sleek, easy to use in-wall DMX Wall Control. Featuring a 16 mode auto play function, with RGBW shortcuts for color mixing and brightness control, and four zone control coupled with DMX decoders and transceivers compatability makes this controller versatile and ideal for many applications. DMX RGB+TW fits single gang junction boxes, and with convenient installation, readily enables total lighting control and full tape light capability.

  • 16 mode auto play function
  • RGB shortcuts for color mixing & brightness control
  • 4 zone and 4 scene keys for easy control
  • Fits single gang junction box
  • Works with DMX decoders and wireless DMX transceiver
DMX RGBW Wall Control
DMX RGBW Wall Control DMX RGBW Wall Control

Performance

Input Voltage
12-24V DC
Input Frequency
60Hz
Output Frequency
DMX
Temperature Range
-20C (-4F) to 55C (131F) degrees
Dimming
DMX 1 -100%
Finish
Black
Control
DMX

Physical

Weight
0.75 lbs
Width
1.15 Inch
Length
2.96 Inch
Height
4.75 Inch

Certification

Safety Rating
UL Listed
Location Rating
Dry
Indoor
Y
ROHS
Y
FCC
Y
Item Number Length Input Voltage UOM
CTRLW-DMXB-RGBW-4Z 2.96 Inch 12-24V DC Each
