Microlink 120V AC

SERIES
C-AML-MLINK-120

Modular, linkable, and now available in 120V AC. The MicroLink 120V AC fixture is a simple and versatile solution for new construction or remodeling applications. Streamline task and accent lighting with sleek, easy-to-install fixtures that brings style to any situation. Quick connect accessories make right angles, left angles, and cross connections easy work in complex installations.

  • 3000K color temperature with 90+ CRI
  • Low-profile fixture fits in a multitude of locations
  • Available in four common size fixture lengths: 6” / 12” / 24” / 36”
  • Lumen output up to 859Lm per fixture
  • 65.6ft maximum link-ability
  • Diffused lens for smooth, evenly distributed light
  • Plug and play system for quick installation
  • cETLus Listed for indoor, dry locations
Microlink 120V AC
Microlink 120V AC Microlink 120V AC Microlink 120V AC Microlink 120V AC

Performance

Input Voltage
120V AC
CCT
3000K
Finish
Satin Aluminum
Wattage
2.4W per 6in Segment
Optics (Degree)
120 Degrees
CRI
90+
Max Run
65.6ft
Rated Life (Hr)
50,000 Hours
Dimming
Dimmable (5-100%) with most ELV, TRIAC dimmers
Lumens
Up to 859Lm

Certification

Safety Rating
cETLus Listed
Location Rating
Dry
Indoor
Y
Item Number Length Input Voltage CCT CRI Wattage Lumens Max Run IP Rating UOM
MLINK-120-30-6 6 Inch 120V AC 3000K 90 2.4 W 130 65.6 ft IP20 Each
MLINK-120-30-12 12 Inch 120V AC 3000K 90 4.8 W 280 65.6 ft IP20 Each
MLINK-120-30-24 24 Inch 120V AC 3000K 90 9.6 W 565 65.6 ft IP20 Each
MLINK-120-30-36 36 Inch 120V AC 3000K 90 14.4 W 859 65.6 ft IP20 Each
