Slim Fit 5CCT

SERIES
C-AML-SF-5CCT

The 120V Slimfit Series offers easy installation and 5 built-in CCT settings that provide 2700K, 3000K, 3500K, 4000K, or 5000K white light. Rated to perform in a variety of settings including wet locations, the Slimfit Series is the perfect choice for retrofitting or updating existing surface mount fixtures.

  • Excellent color rendering (90+ CRI)
  • Five selectable color temperatures: 2700K / 3000K / 3500K / 4000K / 5000K
  • Aluminum housing with polycarbonate lens
  • Available in 5”, 7”, 9” and 12” sizes
  • Lumen output up to 1400 Lumens
  • Dimmable with most TRIAC or ELV dimmers
  • Surface mounts to pancake or standard depth 4” junction box; Required distance between mounting holes: 3-1/2”
  • cETLus Listed for wet locations
  • 50,000 hours rated life
  • Energy Star certified & JA8 Compliant
  • Slim Fit 5CCT
    Slim Fit 5CCT Slim Fit 5CCT

    Performance

    Input Voltage
    120V AC
    CCT
    5CCT (2700K/3000K/3500K/4000K/5000K)
    Finish
    White
    Wattage
    12W / 15W / 18W / 22W
    CRI
    90+
    Lumens
    800Lm / 1000Lm / 1200Lm / 1400Lm

    Certification

    Safety Rating
    cETLus Listed
    Location Rating
    Wet
    Energy Star
    Y
    Title 24
    Y
    Indoor
    Y
    Item Number Length Input Voltage CCT CRI Wattage Lumens UOM
    SL5-5CCT-WH 5 Inch 120V AC 5CCT 90 12 W 800 Each
    SL7-5CCT-WH 7 Inch 120V AC 5CCT 90 15 W 1000 Each
    SL9-5CCT-WH 9 Inch 120V AC 5CCT 90 18 W 1200 Each
    SL12-5CCT-WH 12 Inch 120V AC 5CCT 90 22 W 1400 Each
