Trulux Standard Grade COB Tape Light Static White

SERIES
C-AML-STL-COB

COB Tape Light features uniform illumination without the need for additional diffused covers or accessories. Featuring a premium seamless line of light making it an ideal solution for areas with low clearance or reflective surfaces to eliminate virtually all dotting or spot-glare effects.

  • Seamless COB design that eliminates virtually all LED dotting
  • Available in 2700K, 3000K, 3500K, 4000K, and 5000K
  • 90+ color rendering index
  • Lumen output ranging from 180Lm to 220Lm per foot
  • Cuttable every 1.97” with 16.4ft max run
  • Easy installation featuring 3M VHB adhesive backing
  • Available in IP54 coated rating
  • Dimmable (5-100%) with most ELV, TRIAC dimmers
  • cULus Listed for indoor dry/damp
  • JA8 Compliant
  • 50,000 hours rated life
  • Suitable for use in closets when used in an enclosed extrusion based on NFPA 70, NEC section 410.16 (A)(3) and 410.16 (C)(5)
Trulux Standard Grade COB Tape Light Static White
Trulux Standard Grade COB Tape Light Static White

Performance

Input Voltage
24V DC
CCT
2700K / 3000K / 4000K
Wattage
5W/ft
Optics (Degree)
120 degrees
CRI
90+
Cut Increment
1.97 Inch
Max Run
16.4ft
Rated Life (Hr)
50,000 Hours
Temperature Range
5°C (41°F) to 70°C (158°F)
Dimming
Dimmable (5-100%) with most ELV, TRIAC dimmers
Lumens
448Lm/ft

Certification

Safety Rating
cULus Listed
Item Number Length Input Voltage CCT CRI Wattage Lumens Max Run IP Rating UOM
STL-COB-UWW-16 16.4 Foot 24V DC 2700K 90+ 2.19 W/ft 180 16.4 ft IP54 Each
STL-COB-WW-16 16.4 Foot 24V DC 3000K 90+ 2.19 W/ft 200 16.4 ft IP54 Each
STL-COB-NW-16 16.4 Foot 24V DC 3500K 90+ 2.19 W/ft 200 16.4 ft IP54 Each
STL-COB-WH-16 16.4 Foot 24V DC 4000K 90+ 2.19 W/ft 220 16.4 ft IP54 Each
STL-COB-CW-16 16.4 Foot 24V DC 5000K 90+ 2.19 W/ft 220 16.4 ft IP54 Each
STL-COB-UWW-CC Custom Cut 24V DC 2700K 90+ 2.19 W/ft 180 16.4 ft IP54 Foot
STL-COB-WW-CC Custom Cut 24V DC 3000K 90+ 2.19 W/ft 200 16.4 ft IP54 Foot
STL-COB-NW-CC Custom Cut 24V DC 3500K 90+ 2.19 W/ft 200 16.4 ft IP54 Foot
STL-COB-CW-CC Custom Cut 24V DC 5000K 90+ 2.19 W/ft 220 16.4 ft IP54 Foot
