High Output Tape Light IP54 3000K 5M Kit
SKU
HTL-WW-5MKIT
High Output tape light kits provide the components for a complete Trulux Lighting System. The High Output Kit offers an impressive amount of lumens while staying highly energy efficient. This convenient kit is ideal for undercabinet lighting or other similar task lighting applications where brightness is needed.
- Ready to install 24V Tape Light kit with plug & play connection
- Features handheld remote for easy on/off operation
- 2700K or 3000K color temperatures with 96+ CRI
- Up to 300Lm per foot consuming only 4.6W per foot
- Cuttable every 3.94” with max runs up to 16.4ft
- Includes 3A plug-in power supply with in-line receiver
- Additional tape light accessories included for easy installation
- cULus Listed (dry location)
- 50,000 hours rated life
Performance
Input Voltage
24V DC
Wattage
4.6 W/ft
CCT
3000K
CRI
96+
Lumens
300
Cut Increment
3.94 in
Max Run
16.4 ft
Optics (Degree)
120 degrees
Rated Life (Hr)
50,000 Hours
Temperature Range
5C (41F) to 70C (158F) degrees
Dimming
TRIAC / ELV 5 - 100%
Spacing
0.63 Inch
Physical
Weight
1.90 lbs
Width
0.03 Foot
Length
16.4 Foot
Certification
Safety Rating
cULus Listed
Title 24
Y
IP Rating
IP54
Location Rating
Damp
Indoor
Y
Outdoor
Y
| Item Number | Length | Input Voltage | CCT | CRI | Wattage | Lumens | Max Run | IP Rating | UOM |
|---|---|---|---|---|---|---|---|---|---|
| HTL-WW-5MKIT | 16.4 Foot | 24V DC | 3000K | 96+ | 4.6 W/ft | 300 | 16.4 ft | IP54 | Each |
